Titanium Seamless Pipe
1/8" NPS through 6" NPS (Sch 10S and Sch 40S)
[Other Schedule sizes available on request]

Titanium Welded Pipe
3/4" NPS through 24" NPS (Sch 10S and Sch 40S)
[May be Continuous Rolled & Welded to 8" Sch 40S or Brake Press formed and Welded from 6" NPS and above.]
[Other Schedule sizes available on request.]

Titanium Tube
Titanium Seamless Tube
OD - 1/8" (3.18 mm) to 1-1/2" (38.1mm) Wall - .016" (4 mm) to .065" (1.65 mm) [Other OD Sizes and Walls available on request.]

Welded Tube
OD - 1/2" (12.7 mm) to 2" (50.8 mm) Wall - .028" (.71 mm) to .065" (1.65 mm) [Other OD Sizes and Walls available on request.]

Titanium Plate
.1875" to 3" x up to 96" Wide x to 240" Long
[Wider Widths, Custom and Special Shapes (Circles, Rectangles, Squares and Others) available on request.]
Plate can be Sheared, Saw Cut or Water-Jet Cut to Standard sizes or any Custom size (dependent upon Customer preference and size considerations)

Titanium Sheet
.020" to under .187" x up to 48" Wide x Length
Standard sizes: 48" Wide X 120" Long [Sheet can be sheared to any Custom size.]
[By ASTM definition, Sheet is product .187" (4.75 mm) and under in thickness and 24" (610 mm) or more in width.]

Titanium Bar

Round Bar
.160" Dia. to under 4-1/2" Dia. x RL [ Up to 17-3/4"][Bar can be Saw Cut to any Custom size.] [By ASTM definition, Bar has a cross-sectional area less than 16 in2. Larger sizes, however, are often also referred to as Bar.]

Square Bar
1/4" Square to 1" Square x RL [Up to 14'] Bar can be Saw Cut to any Custom size.
[By ASTM definition, Bar has a cross-sectional area less than 16 in2. Larger sizes, however, are often also referred to as Bar.]

Titanium Rod

Threaded Rod
6-32 through 1-8 x 10' to 12' RL
[Other sizes available on request.]

Titanium Wire

Round Wire
.063" OD through .214" OD x 10' / 12' RL
Weld Wire
.035" OD through .156" OD x 36" Long

Titanium Bolts

Titanium Hex Head Bolt
8-32 through 3/4-10 Lengths through 4"
[Other sizes available on request.]

Titanium Nuts

Titanium Hex Nut
8-32 through 3/4-10
[Other sizes available on request.]

Titanium Screws

Flat Head Slotted Machine Screw
#6 through # 10 and 1/4" through 1/2" x 3/8" through 2-1/2" Long
[Other sizes available on request.]

Flat Head Phillips Machine Screw
# 8 through # 10 and 5/16" through 1/2" x 3/8" through 2-1/2" Long
[Other sizes available on request.]

Pan Head Phillips Machine Screw
# 6 through # 10 and 1/4" through 5/16" x 3/16" through 1-1/2" Long
[Other sizes available on request.]

Pan Head Slotted Machine Screw
# 6 through # 10 and 1/4" through 5/16" x 3/16" through 1-1/2" Long
[Other sizes available on request.]

Titanium Washers

Titanium Flat Washer
#8 through 3/4"
[Other sizes on request

Elbow Short Radius Butt-Welding 90°
1" through 24" NPS Sch 1OS and 40S
[Other Sizes and Schedules available on request.]

Titanium Elbows
Elbow Long Radius Butt-Welding 90°
1/2" through 48" NPS Sch 1OS
and 40S [Other Sizes and Schedules available on request.]

Elbow Long Radius Butt-Welding 45
1/2" through 48" NPS Sch 10S and 40S.

Elbow Threaded 45°
1/4 " through 4" NPS

Elbow Threaded 90°
1/4 " through 4" NPS

Butt Welding Short Branch Straight Tee
1/2" through 24" NPS
(MSS) Sch 10S and 40S
[Other Schedules available on request.]

Blind Flange (Raised Face)
1/2" through 24" NPS (ANSI) & 12" through 60" (MSS) Class 150 through 2500

Slip-On Flange (Raised Face)
1/2" through 24" NPS
(Larger Sizes available on request)

Weld Neck Flange (Raised Face) (Ring-Type Joint)
1/2" through 60" NPS (ANSI) [Raised Face only]
Class 150 through 2500 12" through 60" NPS (MSS)
Class 150 through Class 900 [Raised Face]
Class 300 through Class 900 [Ring-Type Joints

Threaded Flange
1/2" through 24" NPS
Class 150 through 1500
(to 12" NPS max. for Class 2500)
(Larger Sizes available on request)
Lap Joint Pipe Flange
1/2" through 24" NPS
Class 150 through 300
(Larger Sizes available on request)
